BioDELTATM BIOWASTE INACTIVATION (BIOKILL) SYSTEMS
Biological waste produced by pharmaceutical and gene-therapy manufacturing and R & D processes is considered hazardous to human health and therefore requires inactivation before it can be safely discharged to the sewer. Common methods for performing this deactivation utilize either heat, which elevates and holds temperature to "destroy" any existing living microorganisms, or chemicals, which are injected and held at specific concentrations required to eliminate biological waste. Following inactivation, wastewater can be safely discharged to the city sewer.
Wastech’s pre-packaged Biological Waste Inactivation (Biokill) Systems are available in multiple sizes and configurations, and its BioDELTA™ Duo (biokill + pH adjustment) and BioDELTA™ Trio (biokill + pH adjustment + CIP) systems draw seamlessly from its extensive experience in skid mounted pH adjustment systems. Integrating these processes into one system ultimately saves the client money and time by combining what are normally considered two or three separate and expensive systems into one. Since the combined BioDELTA™ Duo or BioDELTA™ Trio systems are designed and fabricated as a single, integrated system there are no compatibility, interface, communication or service issues that typically arise when utilizing multiple skids from multiple vendors. Cost savings can also be enjoyed through a reduction in field installation requirements and operator manpower.
Which type of system is right for your process?
The BioDELTA™ Continuous Thermal Biowaste Inactivation System is a skid-mounted thermal biological inactiviation unit that uses heat and a continuous flow, measured in Gallons Per Minute (GPM), to elevate and hold a high temperature to "destroy" living microorganisms and biological wastes on a continuous basis. Cooling water and heat exchangers are used to cool the waste stream prior to discharging from the skid. Instrumentation installed on the discharge piping monitors and records the effluent temperature, hold time, and flow of the waste being discharged. If for any reason the wastewater does not meet dischargeable specifications the control system automatically recirculates it back to the holding tank for re-treatment.
The BioDELTA™ Batch Biowaste Inactivation System is a skid-mounted thermal biological inactiviation unit that uses heat and a custom-sized holding tank to elevate and hold a high temperature to "destroy" living microorganisms and biological wastes. Ideal for intermittent flows or "batch dumps", biowaste is held in one tank for a predetermined about of time to kill harmful pathogens. Once desired hold time has been reached, cooling water is used to cool the waste stream prior to discharging from the skid. Instrumentation installed on the discharge piping monitors and records the effluent temperature, hold time, and volume of the waste being discharged. Wastewater is never discharged before biwaste discharge permit specifications are met.
Biowaste Inactivation, pH Adjustment & CIP - Three processes, one system.
The BioDELTA™ Duo Thermal Biowaste Inactivation + pH Adjustment System allows for batch or continuous thermal inactivation of biowaste and pH adjustment to be managed in one system under one set of controls. Configurations vary based on customer processes and footprint requirements.
The BioDELTA™ Trio Thermal Biowaste Inactivation + pH Adjustment + CIP System allows for batch or continuous thermal inactivation of biowaste, pH adjustment and CIP processes to be managed in one system under one set of controls. No need to coordinate multiple FAT's, multiple HMI/controls conventions, or multiple service departments. Wastech's team of chemical, mechanical, electrical and controls engineers along with Wastech's department of in-house, factory Field Service engineers ensures one point of contact, one point of responsibility for system performance. Configurations vary based on customer processes and footprint requirements.
Standard Features Include:
- 316L SS or fiberglass holding tank
- 316L SS piping
- Steam heating heat exchanger (Thermal BioKill)
- Thermal retention for complete deactivation (Thermal BioKill)
- Cooling heat exchanger (Thermal BioKill)
- Single stage treatment systems
- 50, 100, 250, 500 and 1,000-gallon batch models available
- 10, 20, 30, 50 and 100 gpm continuous models available
- Alternating duplex transfer pumps with inlet strainers
- UL-Listed control panel
- NEMA 4 powder-coated steel enclosure
- PLC-based control system with color touchscreen HMI
- Dry contacts for common alarm, influent permissive, and temperature out of range
- Run permissive for remote enable/disable
- Temperature probes in process and discharge piping
- Seismic tie-down brackets
- Pumped discharge
- Out-of-Compliance prevention system
- Skid-mounted design, ready to install
- Factory-piped, wired, and tested before shipment
Need a Custom System?
Wastech Controls and Engineering, Inc. offers custom design and engineering of state-of-the-art turnkey industrial process systems.
One of Wastech’s application engineers will discuss the nature of your process with you exclusively for your facility.
